Operational Amplifier Trainer Manufacturer,Supplier and Exporter in India
.png)
Product Code : SCL-EELE-14506
Indian Lab Suppliers supplies the Operational Amplifier Trainer (Product ID: 14506) as part of its electronics engineering lab equipment range. It is a bench trainer for studying operational amplifier characteristics and the standard op-amp circuits.
Quick Answer
An on-board supply converts 230 V AC into regulated ±12 V or ±15 V DC for the op-amp ICs, which are 741 or similar depending on model. Experiment sections cover inverting and non-inverting amplifiers, voltage follower, summing amplifier, integrator, differentiator, comparator, Schmitt trigger and active filters; a Wien bridge oscillator and a built-in sine, square and triangle function generator are optional. Test points take a multimeter or CRO/DSO, and circuits are linked with 4 mm patch cords. The unit is about 300 × 200 × 80 mm and comes with patch cords, a user manual and power cable.
Key Specifications
| Parameter | Detail |
|---|---|
| Input supply | 230 V AC |
| Output rails | ±12 V / ±15 V regulated DC |
| Op-amp ICs | 741 or similar (by model) |
| Experiments | Inverting, non-inverting, voltage follower, summing, integrator, differentiator, comparator, Schmitt trigger, active filters |
| Optional | Wien bridge oscillator; function generator (sine, square, triangle) |
| Protection | Short-circuit and overload |
| Connections | 4 mm banana sockets, test points |
| Size | Approx. 300 × 200 × 80 mm (varies by model) |
| Supplied with | Patch cords, user manual, power cable |
Where This Is Used
Used in analog electronics and linear IC labs in engineering colleges and polytechnics, with waveforms viewed on a CRO or DSO. A similar board with a differential amplifier section is the Operational Amplifier Trainer (Product ID: 14510). It runs from mains, so use an earthed socket. Browse the full Electronics Engineering Lab Equipment range or related Electronics Lab Equipment products.
Frequently Asked Questions
Which op-amp is used?
A 741 or similar, depending on model.
Is a function generator built in?
It is optional; please confirm at quotation.
What comes with the trainer?
Patch cords, a user manual and a power cable.
