Operational Amplifier Trainer Manufacturer,Supplier and Exporter in India
 (1).jpg)
Product Code : SCL-EELE-14510
Indian Lab Suppliers supplies the Operational Amplifier Trainer (Product ID: 14510) as part of its electronics engineering lab equipment range. It is a bench trainer with ready-built op-amp circuits for studying amplifier, comparator and filter applications.
Quick Answer
An on-board dual supply of ±12 V or ±15 V (model-dependent) powers a 741 op-amp, with quad or dual op-amp ICs as options. Pre-built sections cover inverting, non-inverting, differential and summing amplifiers, integrator, differentiator, comparator and Schmitt trigger; RC active filters and oscillators are optional, and some models add a sine, square and triangle signal source. Test points at each stage allow measurement with a meter or oscilloscope, and fuse, overload and short-circuit protection is fitted. Connections use banana or 2 mm patch cords, and the case is laminated MDF or metal. Please confirm the supply rails, optional sections and size at quotation.
Key Specifications
| Parameter | Detail |
|---|---|
| Supply | ±12 V or ±15 V dual (model-dependent) |
| Op-amp IC | 741 (quad/dual op-amp ICs optional) |
| Experiments | Inverting, non-inverting, differential, summing, integrator, differentiator, comparator, Schmitt trigger |
| Optional | RC active filters, oscillators, signal generator |
| Protection | Fuse, overload, short-circuit |
| Connections | Banana or 2 mm patch cords |
| Body | Laminated MDF or metal |
Where This Is Used
Used in linear IC and analog electronics practicals, with outputs traced on a CRO or DSO. Compare with the Operational Amplifier Trainer (Product ID: 14506), which specifies a 230 V AC input and a Wien bridge option. Browse the full Electronics Engineering Lab Equipment range or related Electronics Lab Equipment products.
Frequently Asked Questions
Does it include a differential amplifier?
Yes, along with inverting, non-inverting and summing amplifiers.
Are filters and oscillators included?
They are optional; please confirm at quotation.
What supply rails are provided?
±12 V or ±15 V, depending on model.
Related Categories
Electronics Engineering Lab Equipment · Electronics Lab Equipment · Engineering Lab Equipment
Request a Quote
For pricing, bulk quantities or tender documentation on the Operational Amplifier Trainer, reach our team via Contact Us or submit your requirement through our Tenders page.
