Flow Over Notches (Hb Accessory)

Product Code : SCL-CELE-14020

Indian Lab Suppliers supplies the Flow Over Notches (Hb Accessory) (Product ID: 14020) as part of its Civil Engineering Lab Equipment range. It measures discharge over rectangular and V-notches on a hydraulic bench.

Quick Answer

Water enters a 600 x 250 x 180 mm stainless steel channel from below through a deepened entry section that settles the flow before the notch. Three interchangeable brass notches are supplied: rectangular, 45° V and 60° V. A pointer gauge with vernier reads the head over the crest. It connects to a Hydraulic Bench (Product ID: 14019) by flexible pipe, which supplies the water and measures the flow.

Key Specifications

ParameterDetail
ChannelStainless steel, 600 x 250 x 180 mm, deepened entry
NotchesBrass: rectangular, 45° V, 60° V
Head measurementPointer gauge with vernier

Where This Is Used

Students find Cd for each notch from head-discharge data. A self-contained version is the Discharge Over Notches (Product ID: 13994). Browse the full Civil Engineering Lab Equipment range or related Engineering Lab Equipment apparatus.

Frequently Asked Questions

Which notches are included?
Rectangular, 45° V and 60° V in brass.

Does it need a hydraulic bench?
Yes, for water supply and flow measurement.

How is head read?
With a vernier pointer gauge.

Related Categories

Civil Engineering Lab Equipment · Engineering Lab Equipment · Water and Sanitation

Request a quote: Contact Us or Tenders.
