Indian Lab Suppliers supplies the Ohm Meter Shunt Type Analog (Product ID: 14664) as part of its electrical and electronics range. It is an analog ohmmeter for low resistances, in which the unknown resistor is connected across (in shunt with) the meter movement.
Quick Answer
With the terminals open, the internal battery drives full-scale deflection through the moving-coil movement; the unknown resistor then bypasses part of that current, so a smaller resistance gives a smaller deflection. The scale reads zero at the left, the reverse of a series-type ohmmeter, which makes it suited to low values. Ranges are typically 0–10, 0–20 or 0–100 Ω, accuracy about ±2% of full scale, with a 1.5 V or 3 V cell, zero-setting potentiometer and 4 mm insulated binding posts. A shunt-type ohmmeter draws battery current even with its terminals open, so switch it off or remove the cell when not in use.
Key Specifications
| Parameter | Detail |
|---|---|
| Method | Shunt type, for low resistance |
| Ranges | Typically 0–10, 0–20, 0–100 Ω |
| Movement | Analog moving coil |
| Accuracy | About ±2% FSD |
| Internal battery | 1.5 V or 3 V, by model |
| Terminals | 4 mm insulated binding posts |
| Zero setting | Potentiometer |
| Housing | ABS or powder-coated metal |
Where This Is Used
It is used to measure coil, wire and low-value resistor resistances. Compare the Ohmmeter Series Type (Product ID: 14656) for higher values. Browse the full Electrical and Electronics range or related Lab Meters products.
Frequently Asked Questions
What resistances does it suit?
Low values, typically up to 10, 20 or 100 Ω.
How does it differ from a series ohmmeter?
The resistor is placed across the meter, so zero is at the left.
What battery does it use?
1.5 V or 3 V.
