7 Decade Resistance Box Manufacturer,Supplier and Exporter in India

Product Code : SCL-EAE-14647

Indian Lab Suppliers supplies the 7 Decade Resistance Box (Product ID: 14647) as part of its electrical and electronics range. It is a resistance box with seven rotary-switch decades, from 0.1 Ω steps up to 100 kΩ steps.

Quick Answer

Each of the seven switches sets one decade, with steps of 0.1 Ω, 1 Ω, 10 Ω, 100 Ω, 1 kΩ, 10 kΩ and 100 kΩ, so values from 0.1 Ω to about 1 MΩ can be dialled. Resistors are precision wire-wound or metal film with a low temperature coefficient, and accuracy is ±1% or ±0.5% as ordered. It has 4 mm or 2 mm binding posts in a wooden or metal case. Please confirm the accuracy and power rating at quotation.

Key Specifications

Parameter	Detail
Decades	7, rotary switches
Step values	0.1, 1, 10, 100 Ω; 1, 10, 100 kΩ
Range	0.1 Ω to about 1 MΩ
Accuracy	±1% or ±0.5%
Resistors	Wire-wound or metal film, low temperature coefficient
Terminals	4 mm or 2 mm binding posts
Case	Wood or metal
Operating temperature	0–50 °C

Where This Is Used

It is used for Ohm’s law, Kirchhoff’s laws, Wheatstone bridge and calibration work. Related: Decade Resistance Box, Dial Type (Product ID: 10793) and Resistance Substitution Box (Product ID: 10792). Browse the full Electrical and Electronics range or related Electronics Lab Equipment products.

Frequently Asked Questions

How many decades does it have?
Seven.

What is the smallest step?
0.1 Ω.

What accuracy is offered?
±1% or ±0.5%.
