Pipe Friction Apparatus

Product Code : SCL-CELE-14133

Indian Lab Suppliers supplies the Pipe Friction Apparatus (Product ID: 14133) as part of its Civil Engineering Lab Equipment range. It measures friction factor in a 3 mm stainless steel pipe in laminar and turbulent flow.

Quick Answer

A 3 mm bore, 650 mm stainless steel pipe has tappings 500 mm apart and extra length for fully developed flow. Low flows come from a 10 L constant-head tank (600 mm long, 140 mm ID) and high flows from a hydraulic bench. A 200 mm mercury U-tube or 400 mm water manometer reads the loss, and a 2 L/min flow meter with needle valve or a 5 L measuring cylinder gives flow.

Key Specifications

ParameterDetail
Test pipeStainless steel, 3 mm bore, 650 mm, tappings 500 mm apart
Header tank10 L, 600 mm long x 140 mm ID
ManometersMercury 200 mm; water 400 mm wc
Flow meter2 L/min with needle valve
Included5 L measuring cylinder, hand pump, 100 mm pipe sample
Size1.2 x 0.4 x 0.9 m
Power240 V, 1 phase, 50 Hz

Where This Is Used

Related: Pressure Losses in Pipes Apparatus (Product ID: 14118) and Fluid Friction Apparatus (Product ID: 14018). Browse the full Civil Engineering Lab Equipment range or related Engineering Lab Equipment apparatus.

Frequently Asked Questions

What is the pipe made of?
Stainless steel, 3 mm bore.

Can laminar flow be studied?
Yes, using the constant-head tank.

What manometers are supplied?
Mercury and water manometers.
