Product Code : SCL-EELE-14505
An Analog & Digital IC Trainer Kit is a comprehensive training system designed for teaching, learning, and experimenting with the fundamentals of analog and digital electronics. Ideal for schools, colleges, TVET institutes, engineering labs, and electronics workshops, this kit enables students to perform hands-on experiments with logic gates, flip-flops, counters, amplifiers, and various analog circuits using real Integrated Circuits (ICs).
It is a ready-to-use platform equipped with power supply modules, breadboards, test points, switches, LEDs, function sections, and IC sockets, making it a complete solution for understanding circuit behavior and IC applications.
Key Features
- Dual-Function Design: Supports both analog and digital experiments in a single trainer kit.
- Built-In Power Supply: Regulated +5V, ±12V or as per model specification for IC operation.
- High-Quality Breadboard: Solderless breadboard for rapid prototyping.
- Multiple Input/Output Indicators: Toggle switches, push buttons, and LED indicators for clear logic visualization.
- IC Compatibility: Supports TTL, CMOS, Op-Amp ICs, timers, counters, and basic analog ICs.
- Short-Circuit Protection: Ensures safe usage during student experiments.
- Durable Body: Rugged, anodized or powder-coated casing for long-term lab use.
- Clear Labelling: All test points and pathways are clearly marked for easy understanding.
- Hands-On Learning: Enables practical understanding of electronics concepts.
Technical Specifications
- Power Supply:
- +5V regulated (Digital)
- ±12V or ±15V regulated (Analog)
- Breadboard: High-quality, solderless, minimum 800 tie-points
- Input Switches: 8 tactile/slide switches for logic inputs
- Indicators: LED logic indicators (8 or more)
- IC Sockets: Multiple sockets with test points
- Function Sections:
- Logic gates (AND, OR, NOT, NAND, NOR, XOR)
- Flip-flops (SR, JK, D)
- Counters and timers (IC 555, IC 7414518, etc.)
- Basic analog circuits (Amplifiers, Filter setups depending on model)
- Protection: Fuse/over-current protection
- Connectivity: 2mm or 4mm banana sockets
- Build Material: Metal or reinforced ABS enclosure
Specifications may vary slightly depending on the model.
Why Choose an Indian Lab Supplier for This Product
- Indian suppliers offer precision-designed trainer kits built to meet global educational and industry standards.
- Significantly more affordable compared to imported trainer kits, without compromise on quality.
- Ability to provide custom experiment setups, additional modules, or institution-specific layouts.
- Products are made to withstand repetitive student handling.
- Quick local support for ICs, wiring kits, and power modules.
- Local suppliers provide faster shipping and quick technical guidance for lab setups.
- Widely adopted in engineering colleges, polytechnic institutes, ITIs, and TVET centers across India.
