Flocculation Test Demo Apparatus Manufacturer,Supplier and Exporter in India
.jpg)
Product Code : SCL-CELE-14169
Overview
The Flocculation Test Demonstrator,
commonly known as the Jar Test Apparatus, is a laboratory-scale unit
designed to study coagulation and flocculation processes used in water
and wastewater treatment. This apparatus helps determine the optimum
coagulant dosage, ideal pH, and mixing conditions required
for effective removal of turbidity, color, and suspended impurities from
water.
The trainer features six glass flocculating
vessels, each equipped with stainless steel paddle stirrers driven
by a variable speed motor. The entire assembly is mounted on a translucent
illuminated base, allowing clear visibility of the floc formation process.
A digital speed indicator and timer provide precise control and
repeatability of experiments.
This equipment is essential for students and professionals in environmental
engineering, chemical engineering, and water treatment to understand the
practical aspects of coagulation and flocculation.
Key
Features
- Six test positions with
individual glass flocculating vessels.
- Variable-speed motor-driven stirrers with digital speed control and display.
- Illuminated translucent base for
clear observation of floc formation.
- Stainless steel paddle impellers, easy
to remove and clean.
- Digital timer (1–99
minutes) with two adjustable preset programs for test
standardization.
- Durable and compact design,
suitable for laboratory or field applications.
- Detailed Operation & Maintenance Manual included.
Technical
Specifications
|
Component |
Specification |
|
Number of Stirrers |
6 Nos. |
|
Paddle Material |
Stainless Steel (SS) |
|
Motor Type |
Variable-speed motor with electronic feedback speed control |
|
Speed Range |
25 – 240 rpm (digitally displayed) |
|
Timer |
Digital, range 1 – 99 minutes, with 2 adjustable preset programs |
|
Base |
Translucent base with fluorescent illumination and reflector |
|
Stirrer Assembly |
Easily demountable for vessel removal and cleaning |
|
Dimensions (Approx.) |
Height: 0.46 m × Length: 0.75 m × Width: 0.21 m |
|
Power Supply |
230 V AC, Single Phase, Earthed |
Experimental
Capabilities
- Determination of optimum coagulant dosage for turbidity
removal.
- Determination of optimum pH for effective coagulation and
flocculation.
- Study of the effect of mixing time and intensity on the
aggregation of particles.
- Observation of floc formation, settling behavior, and clarification
efficiency.
Educational
Objectives
- Understand the principles of coagulation and flocculation in
water treatment.
- Learn how chemical dosage, pH, and mixing conditions affect
floc formation.
- Analyze and compare settling characteristics of treated and
untreated samples.
- Develop practical skills in conducting Jar Tests for process
optimization.
Required
Services
|
Service |
Specification |
|
Electrical Supply |
230 V AC, Single Phase, Earthed |
Documentation
Comprehensive Operation & Maintenance
Manual provided, including:
- Experimental setup and operating instructions
- Theoretical background and standard Jar Test procedure
- Data recording and analysis templates
- Maintenance and safety guidelines
