Filterability Index Unit Demo Manufacturer,Supplier and Exporter in India
.png)
Product Code : SCL-CELE-14172
Overview
The Filterability Index Unit Demonstrator
is a compact bench-top experimental apparatus designed to study the
process of filtration through porous media and to evaluate the filterability
index of various suspensions. This index is a key parameter for assessing
the performance of deep-bed filters in water and wastewater treatment.
The setup enables controlled filtration of
water containing suspended solids through a sand or granular medium, with
accurate measurement of flow rate and pressure drop across the
filter bed. The apparatus is constructed from non-corrosive materials
and incorporates transparent components and tubing for clear
visualization of the filtration process.
A detailed Operation & Maintenance
Manual is included to assist in experiment setup, operation, data analysis,
and maintenance.
Key
Features
- Compact benchtop unit
designed for easy operation and student use.
- Constructed from non-corrosive materials for long service
life.
- Transparent components and tubing allow
full observation of filtration behavior.
- Includes precision flowmeter and differential manometer
for accurate monitoring.
- Removable filter cartridge
enables comparison of different granular media.
- Gravity-fed system for
controlled and consistent operation.
- Suitable for studying fundamentals of filter design, media
characteristics, and filtration performance.
Technical
Specifications
|
Component |
Specification |
|
Feed Vessel |
Capacity: 1.5 liters; Material: Glass |
|
Filter Unit |
Height: 60 mm; Cell Diameter: 38 mm |
|
Flowmeter |
Range: 20 – 280 ml/min |
|
Water Manometer |
Range: 0.5 m |
|
Dimensions |
Height: 0.97 m; Width: 0.45 m; Depth: 0.25 m |
|
Construction |
Non-corrosive, transparent acrylic and stainless steel components |
|
Mounting |
Compact bench-top frame with stable base |
Experimental
Capabilities
- Measurement of the filterability index for a given suspension.
- Study of the performance of a standard water quality test.
- Observation of filtration behavior through various filter media.
- Determination of pressure drop
across a filter bed at different flow rates.
- Evaluation of pre-treatment effectiveness prior to filtration.
- Calculation of filterability index number based on
experimental data.
Educational
Objectives
- Demonstrate the basic principles of deep-bed filtration.
- Understand the relationship between flow rate, head loss, and
media type.
- Learn methods of calculating and interpreting filterability
index.
- Examine the influence of filter media characteristics on
filtration efficiency.
Required
Services
|
Service |
Specification |
|
Water Supply |
Tap water connection |
|
Drainage |
Required for filtered discharge |
Documentation
Each unit is supplied with a comprehensive
Operation & Maintenance Manual, including:
- Detailed setup and operation procedures
- Theoretical background and equations
- Data recording and result analysis templates
- Maintenance and calibration instructions
