Product Code : SCL-EAE-14652
Indian Lab Suppliers supplies the Zener Diode Apparatus (Socket Type) (Product ID: 14652) as part of its electrical and electronics range. It is a panel apparatus for plotting forward and reverse V–I characteristics of Zener diodes that plug into a socket.
Quick Answer
Zener diodes of 5.1 V, 6.8 V and 9.1 V can be swapped in the socket, so several breakdown voltages can be compared on one panel. A built-in 0–12 V variable DC supply drives the circuit, read on a 0–20 V voltmeter and a 0–100 mA ammeter. The panel has a printed circuit diagram, 4 mm banana sockets, overload protection and a fuse. Please confirm how many diodes are supplied and whether the meters are digital or analog at quotation.
Key Specifications
| Parameter | Detail |
|---|---|
| Zener diodes | 5.1 V, 6.8 V, 9.1 V, socket mounted |
| Power supply | Built in, 0–12 V DC variable |
| Voltmeter | 0–20 V |
| Ammeter | 0–100 mA |
| Terminals | 4 mm banana sockets |
| Protection | Overload, fuse |
| Enclosure | Metal or ABS |
Where This Is Used
It is used to observe breakdown voltage and to show a Zener diode as a voltage regulator. Related: Digital Zener Diode Apparatus (Product ID: 14659) and Zener Diode Unit (Product ID: 14624). Browse the full Electrical and Electronics range or related Electronics Lab Equipment products.
Frequently Asked Questions
Which Zener voltages can be tested?
5.1 V, 6.8 V and 9.1 V, swapped in the socket.
What supply is built in?
A 0–12 V variable DC supply.
What are the meter ranges?
0–20 V and 0–100 mA.
