Product Code : SCL-CELE-14166
Indian Lab Suppliers supplies the Open & Closed Flow Channel Apparatus (Product ID: 14166) as part of its Civil Engineering Lab Equipment range. It studies both closed-conduit and open-channel flow in one clear acrylic working section.
Quick Answer
The clear acrylic working section is 75 mm wide, 150 mm high and 1100 mm long, with a bed that an external actuator raises or lowers even during running. As a closed conduit it shows Bernoulli and continuity in converging and diverging sections, with three adjustable Pitot tubes and a multi-tube manometer. As an open channel it takes sharp and broad-crested weirs, overshot weirs and a sluice gate to study hydraulic jumps, drops and Froude number effects. It stands on a castored steel frame and is fed from a hydraulic bench.
Key Specifications
| Parameter | Detail |
|---|---|
| Working section | Clear acrylic, 75 x 150 x 1100 mm |
| Modes | Open channel or closed conduit |
| Bed | Height adjustable by external actuator |
| Measurement | Multi-tube manometer; 3 adjustable Pitot tubes |
| Structures | Sharp and broad-crested weirs, overshot weir, sluice gate |
| Frame | Floor-standing, powder-coated, castors |
| Power | 220 V, 1 phase, 0.5 kW |
| Floor area | 1.5 x 0.75 m |
Where This Is Used
Use it with a Hydraulic Bench (Product ID: 14019). Related: Flow Channel Apparatus (Product ID: 14121) and Hydraulic Flow Demo Unit (Working section 77mm wide, 150mm high and 1100mm long) With Hydraulic Bench Optional (Product ID: 14179). Browse the full Civil Engineering Lab Equipment range or related Engineering Lab Equipment apparatus.
Frequently Asked Questions
Can it run as a closed pipe?
Yes, as a closed conduit or an open channel.
Can the bed be adjusted while running?
Yes, with an external actuator.
How many Pitot tubes are fitted?
Three.
