BIO-Signal Simulator ECG/EEG/EMG/HR Manufacturer,Supplier and Exporter in India

Product Code : SCL-MDE-12430

Indian Lab Suppliers offers the Bio-Signal Simulator, ECG/EEG/EMG/HR (4-Parameter) (Product ID: 12430) as part of its Medical Diagnostic Equipment range under Hospital Lab Equipment. This is a combined signal-generation instrument covering four biomedical signal types – ECG, EEG, EMG and Heart Rate/Respiration pulse – on one unit, and sits alongside our dedicated single-signal simulators within the same test/calibration instrument family.

Quick Answer

This is a 4-parameter Bio-Signal Simulator used for calibration and testing of ECG, EEG and EMG instruments, plus a pulse output for Heart Rate or Respiration, with a selector switch to choose any three parameters (or a single one) at a time. It generates a 5-lead ECG signal (standard PQRST, 0–5mV amplitude, 30–120 BPM adjustable rate), a 3-lead differential EEG signal across the Delta/Theta/Alpha/Beta/Gamma bands (0–20mV amplitude), and a 3-lead differential EMG signal (0–20mV amplitude, frequency adjustable 0–1kHz), making it a versatile bench reference for testing amplifiers, recorders and monitors.

Key Features

4-parameter Bio-Signal Simulator: ECG, EEG, EMG and HR/Respiration pulse · Selector switch for any 3 parameters, or a single parameter · 5-lead ECG (RA, LA, RL, LL, V) with standard PQRST waveform · ECG amplitude 0 to 5mV, rate 30 to 120 BPM adjustable, with audible & visible indication · 3-lead differential EEG across Delta, Theta, Alpha, Beta and Gamma bands, amplitude 0 to 20mV · 3-lead differential EMG, amplitude 0 to 20mV, frequency adjustable 0 to 1kHz · Universal output sockets on every channel, for connection to amplifiers, recorders or monitors

Key Specifications

Parameter	Specification
Application	Calibration & testing of ECG, EEG, EMG instruments, amplifiers, recorders and monitors; pulse output for Heart Rate/Respiration
Selection	Select 3 parameters, or any single one, via selector switch
ECG channel	5-lead (RA, LA, RL, LL, V), universal sockets; standard PQRST signal; amplitude 0 to 5mV (±); rate 30 to 120 BPM (±) adjustable; audible & visible indication
EEG channel	Differential, 3-lead, universal sockets; bands δ, θ, α, β, γ; differential output A, R & G; amplitude 0 to 20mV (±); fixed frequency per band
EMG channel	Differential, 3-lead, universal sockets; differential output A, R & G; amplitude 0 to 20mV (±); frequency adjustable 0 to 1kHz (±)
Pulse output	Related to the ECG simulator; used for calibrating/testing ECG, EMG, EEG, Heart Rate and Respiration Rate instruments
Power supply	230V / 50Hz
Dimensions	Approx. 300 x 100 x 250mm (±)
Standard accessories	Operating manual covering instrument working, operating & installation procedure, block diagrams, connection diagrams, electrode placement, standard signals & actual output signal, calculations, tables, troubleshooting, and an experiments list

Where This Is Used

This simulator is intended for hospitals, biomedical equipment repair centres, and testing/calibration and biomedical instrumentation training laboratories that need a single reference source covering ECG, EEG, EMG and HR/respiration signals. It complements our dedicated single-parameter simulators – the ECG Simulator Portable, EEG Simulator Trainer Kit and EMG Simulator (3-Lead) – within the wider Medical Diagnostic Equipment range. Browse the full laboratory equipment range for related diagnostic and testing instruments.

Frequently Asked Questions

What signal types does this simulator generate?
Four: ECG (5-lead), EEG (3-lead differential, across the standard frequency bands), EMG (3-lead differential), and a pulse output for Heart Rate or Respiration.

Can I run all four signals at once?
The selector switch lets you choose up to three parameters at a time, or focus on a single one.

What are the ECG channel's key specifications?
5-lead output with a standard PQRST waveform, amplitude adjustable 0 to 5mV, and rate adjustable 30 to 120 BPM, with audible and visible rate indication.

How does this differ from your single-signal simulators?
This unit combines ECG, EEG and EMG signal generation plus a pulse output on one instrument, whereas our dedicated ECG, EEG and EMG simulators each focus on a single signal type with a deeper feature set for that signal.

What equipment can this be used to test?
ECG, EEG and EMG instruments, amplifiers, recorders and monitors.
