Fluid Mixing And Power Consumption In Agitated Vessel Manufacturer,Supplier and Exporter in India

Fluid Mixing And Power Consumption In Agitated Vessel

Product Code : SCL-CELE-13491

Indian Lab Suppliers supplies the Fluid Mixing And Power Consumption In Agitated Vessel (Product ID: 13491) as part of its Civil Engineering Lab Equipment range. It measures power consumption and mixing in a baffled stirred tank.

Quick Answer

A stainless steel tank 300 mm in diameter and 400 mm deep has four detachable 2 in baffles and four sampling points. A variable-speed FHP motor drives interchangeable propeller and turbine impellers. A non-contact digital RPM indicator, a 0 to 300 V voltmeter and a 0 to 5 A ammeter give speed and power input.

Key Specifications

ParameterDetail
TankStainless steel, 300 mm dia x 400 mm deep
ImpellersPropeller and turbine, stainless steel
Baffles4, 2 in wide, detachable
DriveVariable-speed FHP motor
InstrumentsDigital RPM indicator, voltmeter 0-300 V, ammeter 0-5 A
Sampling points4

Where This Is Used

Students plot power number against Reynolds number with and without baffles. See also the Ribbon Mixer (Product ID: 13489). Browse the full Civil Engineering Lab Equipment range or related Engineering Lab Equipment apparatus.

Frequently Asked Questions

Which impellers are supplied?
A propeller and a turbine.

Are the baffles removable?
Yes, all four are detachable.

How is power measured?
From motor voltage and current.
