Conversion of Galvanometer into Ammeter Manufacturer,Supplier and Exporter in India

Product Code : SCL-LM-14585

Indian Lab Suppliers supplies the Conversion of Galvanometer into Ammeter (Product ID: 14585) as part of its lab meters range. This apparatus shows how a shunt resistor turns a sensitive galvanometer into an ammeter.

Quick Answer

A moving-coil galvanometer, typically 30–50 µA full scale, is mounted with a low-value precision shunt on a wooden or ABS base with brass terminals. The shunt carries most of the current, so the galvanometer reads only a fixed fraction; the shunt value is S = I_gG/(I − I_g), where G is the galvanometer resistance and I the new full-scale current. The scale is 0–30 or 50–0–50 depending on the model. Please confirm the galvanometer sensitivity and the converted range at quotation.

Key Specifications

Parameter	Detail
Galvanometer	Moving coil, typically 30–50 µA FSD
Scale	0–30 or 50–0–50
Shunt	Low-value precision resistor
Base	Wooden or ABS
Terminals	Brass

Where This Is Used

Used in school and college practicals on meter sensitivity and current division. Compare with the Galvanometer (Product ID: 10823) and Ammeter (Product ID: 10822). Browse the full Lab Meters range or related Electrical and Electronics products.

Frequently Asked Questions

How is the galvanometer converted?
By connecting a low-value shunt in parallel with it.

What sensitivity is the galvanometer?
Typically 30–50 µA full scale.

What scales are available?
0–30 or 50–0–50.

Related Categories

Lab Meters · Electrical and Electronics · Electricity and Magnetism

Request a Quote

For pricing, bulk quantities or tender documentation on the Conversion of Galvanometer into Ammeter, reach our team via Contact Us or submit your requirement through our Tenders page.
