Analog & Digital IC Trainer Kit Manufacturer,Supplier and Exporter in India
.jpg)
Product Code : SCL-EELE-14505
Indian Lab Suppliers supplies the Analog & Digital IC Trainer Kit (Product ID: 14505) as part of its electronics engineering lab equipment range. It is a bench trainer for building and testing both digital logic and analog IC circuits on one board.
Quick Answer
The kit has a regulated +5 V supply for digital ICs and a ±12 V or ±15 V supply for analog work, a solderless breadboard of at least 800 tie-points, 8 logic input switches and 8 or more LED logic indicators. IC sockets with test points take TTL and CMOS logic, op-amps and timers such as the 555. Students wire logic gates, SR, JK and D flip-flops, counters and timers, and basic amplifier and filter circuits. Fuse or over-current protection guards against wiring mistakes. Supply rails, socket size (2 mm or 4 mm) and enclosure (metal or ABS) vary by model, so please confirm them at quotation.
Key Specifications
| Parameter | Detail |
|---|---|
| Digital supply | +5 V DC regulated |
| Analog supply | ±12 V or ±15 V DC regulated |
| Breadboard | Solderless, min. 800 tie-points |
| Inputs | 8 tactile or slide switches |
| Indicators | 8 or more LED logic indicators |
| IC support | TTL, CMOS, op-amps, 555 timer, counters |
| Protection | Fuse / over-current |
| Connectors | 2 mm or 4 mm banana sockets |
| Enclosure | Metal or reinforced ABS |
Where This Is Used
Used in first and second-year electronics labs for logic-gate truth tables, flip-flop and counter experiments, and simple op-amp circuits. For single-purpose boards see the Digital IC Trainer (Product ID: 14507) and the Operational Amplifier Trainer (Product ID: 14506). Browse the full Electronics Engineering Lab Equipment range or related Electronics Lab Equipment products.
Frequently Asked Questions
Can it be used for both analog and digital experiments?
Yes, it has a +5 V digital rail and a ±12 V or ±15 V analog rail on one board.
How many logic inputs and outputs are there?
8 input switches and 8 or more LED indicators.
Is a breadboard included?
Yes, a solderless breadboard of at least 800 tie-points.
Related Categories
Electronics Engineering Lab Equipment · Electronics Lab Equipment · Engineering Lab Equipment
Request a Quote
For pricing, bulk quantities or tender documentation on the Analog & Digital IC Trainer Kit, reach our team via Contact Us or submit your requirement through our Tenders page.
