V-Notch Weir (Flow Channel Accessory)

Product Code : SCL-CELE-13427

Indian Lab Suppliers supplies the V-Notch Weir (Flow Channel Accessory) (Product ID: 13427) as part of its Civil Engineering Lab Equipment range. It is a brass triangular-notch weir plate for measuring flow in an open channel.

Quick Answer

The 3 mm brass plate has 45°, 60° and 90° notches. Discharge is found from the head of water over the notch. It fits inside the flow channel with rubber packing at the sides, is easily removed, and is sized to suit the channel cross-section. V-notch weirs are also used to measure seepage flows in dam safety monitoring.

Key Specifications

ParameterDetail
MaterialBrass, 3 mm
Notch angles45°, 60°, 90°
FittingRemovable, rubber side packing
SizeTo suit channel cross-section

Where This Is Used

Use it in the Tilting Bed Flow Channel (Product ID: 13425) alongside the Rectangular Notch Weir (Flow Channel Accessory) (Product ID: 13428). Browse the full Civil Engineering Lab Equipment range or related Engineering Lab Equipment apparatus.

Frequently Asked Questions

Which notch angles are available?
45°, 60° and 90°.

What is it made of?
3 mm brass.

How is it fitted?
It slides into the channel with rubber packing at the sides.

Related Categories

Civil Engineering Lab Equipment · Engineering Lab Equipment · Water and Sanitation

Request a Quote

For pricing, bulk quantities or tender documentation on the V-Notch Weir (Flow Channel Accessory), reach our team via Contact Us or submit your requirement through our Tenders page.
