Radial Flow Turbine

Product Code : SCL-CELE-14134

Indian Lab Suppliers supplies the Radial Flow Turbine (Product ID: 14134) as part of its Civil Engineering Lab Equipment range. It demonstrates the reaction turbine principle with compressed air.

Quick Answer

Compressed air (0.5-8.5 bar via a regulator) leaves a 50 mm rotor through four 1.5 mm nozzles, turning it by reaction inside a transparent housing, up to about 25 W at 30,000 rpm. An air-cooled band brake with force sensor measures torque, an optical sensor measures speed (0-50,000 rpm), a rotameter measures air flow (25-315 L/min), and gauges read inlet and outlet pressure. A quick-action valve stops it on over-speed.

Key Specifications

ParameterDetail
Rotor50 mm, 4 nozzles of 1.5 mm
OutputAbout 25 W at 30,000 rpm
Air pressure0.5-8.5 bar, regulated
TorqueBand brake with force sensor
SpeedOptical sensor, 0-50,000 rpm
Air flowRotameter, 25-315 L/min
PressureInlet 0-2.5 bar; outlet 0-0.1 bar
ServicesCompressed air 6-10 bar, up to 300 L/min; 230 V 50 Hz or 120 V 60 Hz

Where This Is Used

It draws analogies with steam and water reaction turbines. Related: Impulse Turbine Apparatus (Product ID: 14144) and Reaction Turbine (150W) (Product ID: 14190). Browse the full Civil Engineering Lab Equipment range or related Engineering Lab Equipment apparatus.

Frequently Asked Questions

What drives it?
Compressed air.

What is the maximum output?
About 25 W at 30,000 rpm.

What air supply is needed?
6-10 bar, up to 300 L/min.
