Advanced Digital Communication Training System Manufacturer,Supplier and Exporter in India

Advanced Digital Communication Training System

Product Code : SCL-CE-12498

Indian Lab Suppliers supplies the Advanced Digital Communication Training System (Product ID: 12498), part of the Communication Equipment range under Laboratory equipment, a DDS (Direct Digital Synthesis)-based trainer covering a wide range of digital modulation and demodulation techniques — BPSK, DPSK, QPSK, QAM, MSK, DPCM and ADPCM — on a single system.

Quick Answer

This trainer is designed using advanced Direct Digital Synthesis (DDS) technology on silicon, with LED indications to show the status of each experiment and a descriptive experimental manual. It covers clock and signal generation, a full digital transmitter section (differential, dibit and tribit encoding, scrambling, and BPSK, DPSK, QPSK, QAM, MSK, DPCM and ADPCM modulation) and a matching receiver section (the corresponding decoders and demodulators, digital PAM, error-bit and inter-symbol-interference study, and low-pass Butterworth filters), letting students study an entire digital communication chain on one system.

Key Features

Designed using advanced DDS technology on silicon · LED indications show the status of each experiment · descriptive experimental manual included.

Clock and Signal Generation

ParameterDetail
Sine wave Fixed frequency 1 kHz, 0–2V
Carrier Synchronized carriers at 0°, 90°, 180° and 270° phase
Data pattern 8-bit, 16-bit and 24-bit
PRBS generator 16-bit, switch selectable
Noise White noise, 0–2 Vpp
Transmitter clocks 16 kHz, 32 kHz, 64 kHz, 128 kHz, 256 kHz, 512 kHz and 1.024 MHz
Output 4-digit, 7-segment LED bank
Input Three 8-bit switch banks for data generation

Transmitter Section

Differential encoder · dibit encoder · tribit encoder · scrambler · BPSK and DPSK modulation · QPSK modulation · QAM modulation · MSK modulation · DPCM and ADPCM modulation.

Receiver Section

Differential decoder · dibit decoder · tribit decoder · unscrambler · BPSK and DPSK demodulation · QPSK demodulation · QAM demodulation · MSK demodulation · DPCM and ADPCM demodulation · digital PAM · error-bit adder and inter-symbol interference study · low-pass Butterworth filters.

Experiments

Study of BPSK modulation and demodulation · study of DPSK modulation and demodulation · study of the dibit data encoder · study of QPSK modulation and demodulation and its constellation diagram · study of the tribit data encoder · study of QAM modulation and demodulation and its constellation diagram · study of MSK modulation and demodulation · study of pulse amplitude modulation of digital data for baseband transmission · study of transmission and reception of a band-limited pulse train in a baseband transmission system · study of the eye pattern · measurement of bit error rate using digital data · study of the message scrambler and unscrambler · study of DPCM and ADPCM modulation and demodulation · study of quantization noise in DPCM.

Where This Is Used

This Advanced Digital Communication Training System is used in electronics and communication engineering education to teach a complete digital modulation and demodulation curriculum on one platform, complementing our broader Electronics Lab Equipment and Engineering Lab Equipment ranges, including our related Sampling & Reconstruction Trainer (Product ID 12489) and its companion digital communication trainers.

Why Buy from Indian Lab Suppliers

Indian Lab Suppliers is an India-based laboratory equipment manufacturer and exporter supplying this Advanced Digital Communication Training System alongside its broader Communication Equipment catalog, with documentation such as a Certificate of Origin available on request for institutional and export orders.

Frequently Asked Questions

Which modulation techniques can be studied on this system?
BPSK, DPSK, QPSK, QAM, MSK, DPCM and ADPCM, each with matching transmitter and receiver sections and constellation-diagram study for QPSK and QAM.

Can I measure bit error rate on this trainer?
Yes, the system includes an on-board bit error rate (BER) measurement experiment alongside eye-pattern and inter-symbol-interference studies.

Do you supply this equipment for institutional or export orders outside India?
Yes. Indian Lab Suppliers quotes equipment for institutional and tender buyers across export markets — see the Tenders page for documentation requirements.

Related Categories

Laboratory · Electronics Lab Equipment · Engineering Lab Equipment

Request a Quote

For pricing, bulk quantities or tender documentation on the Advanced Digital Communication Training System, reach our team via Contact Us or submit your requirement through our Tenders page.
